Standard Elements - Dimensions : 75mm L x 43mm Dia
Long Elements - Dimensions : 135mm L x 43mm Dia
Stainless lifetime elements and E85 Safe
Micron | Length | Maximum Flow Rate @ 3Bar* | Part Number |
---|---|---|---|
10 | Standard | 1500LPH | ALY-082-10 |
10 | Long | 2200LPH | ALY-082-10L |
40 | Standard | 1800LPH | ALY-082-40 |
40 | Long | 2600LPH | ALY-082-40L |
75 | Standard | 2100LPH | ALY-082-75 |
75 | Long | 3000LPH | ALY-082-75L |
100 | Standard | 2400LPH | ALY-082-100 |
*Maximum flow rate measured with a pressure drop across the filter of 2psi
